Needle Butterfly Standard Winged Set Gauge 23 0.6x19 Mm With Wings
Regular Price
€1.10
Special Price
€0.67
-39%
Save: €0.43
Out of stock
- box Delivery in Italy in 24/48 and free returns
- star3.000+ positive reviews
- dropboxOver 60,000 products in the catalog
Manufacturer
ICU MEDICAL ITALIA
SKU
915298347
EAN
0304090007902
Butterfly Standard
Winged Set product CE 0050, class IIa.
Butterfly needles for infusions and / or samples, with needle, guide wings and connecting cannula.
Anti-slip system on the wing of the device (Needle easy to insert into the vein without slipping at the time of application). Designed to connect another device in accordance with harmonized standards to ensure a complete connection to the other device. Female Luer closure designed in accordance with harmonized standards EN-1707, ANSI / HIMA MD 70.1. The identification by color code is made in accordance with ISO 6009: 1992.
List of components
All the materials used in the construction of the needles are medical grade and LATEX FREE. The tubing is DEHP FREE and resistant to crushing. The system consists of:
• polypropylene luer cap;
• Stainless SUS-304 steel needle;
• PVC fins and cannula - NOT DEHP;
• ABS luer connector;
• epoxy glue.
Wrapping and packing
Individually packaged product type blister with PET / PE coating. Each package (indivisible) contains 50 pcs. The outer packaging in double corrugated cardboard boxes contains 20 packs, for a total of 1000 units. Each single unit is marked with a lot number, period of validity and information on sterilization methods. All products are packaged according to the BS EN 868-5 / 1999 standard which applies to products that need to be sterilized.
Sterilization
ETHYLENE OXIDE. Sterile disposable hypodermic needles conforming to ISO 7864: 1993. Sterility is ensured by the individual packaging of each unit and by an indicator affixed to the outer carton.
Warnings
For single use only. Do not resterilize.
storage
Store in a dry and clean place.
Validity
5 years (from sterilization) to intact packaging and if stored correctly.
Biocompatibility
All materials are biocompatible in accordance with ISO / ANSI / AAMI 10993.
Product certification
Compliant with Directive 93 / 42CEE (Annex II) (implemented by legislative decree February 24, 1997, n. 46) and subsequent additions.
Cod. 391810901/391811001/391811201/391811301/391811401
Winged Set product CE 0050, class IIa.
Butterfly needles for infusions and / or samples, with needle, guide wings and connecting cannula.
Anti-slip system on the wing of the device (Needle easy to insert into the vein without slipping at the time of application). Designed to connect another device in accordance with harmonized standards to ensure a complete connection to the other device. Female Luer closure designed in accordance with harmonized standards EN-1707, ANSI / HIMA MD 70.1. The identification by color code is made in accordance with ISO 6009: 1992.
| Code | Needle gauge | Needle Length | Tubing length | Color | Fill volume | Flow rate |
| 391810901 | 19 G (1.1 mm) | 3/4 "- 19 mm | Series 12 inches 300 mm | cream | 0.47 ml | 51.2 ml / min |
| 391811001 | 21 G (0.8 mm) | green | 0.44 ml | 26.6 ml / min | ||
| 391811201 | 23 G (0.6 mm) | heavenly | 0.44 ml | 9.2 ml / min | ||
| 391811301 | 25 G (0.5 mm) | orange | 0.45 ml | 4.3 ml / min | ||
| 391811401 | 27 G (0.4 mm) | Grey | 0.44 ml | 0.6 ml / min |
List of components
All the materials used in the construction of the needles are medical grade and LATEX FREE. The tubing is DEHP FREE and resistant to crushing. The system consists of:
• polypropylene luer cap;
• Stainless SUS-304 steel needle;
• PVC fins and cannula - NOT DEHP;
• ABS luer connector;
• epoxy glue.
Wrapping and packing
Individually packaged product type blister with PET / PE coating. Each package (indivisible) contains 50 pcs. The outer packaging in double corrugated cardboard boxes contains 20 packs, for a total of 1000 units. Each single unit is marked with a lot number, period of validity and information on sterilization methods. All products are packaged according to the BS EN 868-5 / 1999 standard which applies to products that need to be sterilized.
Sterilization
ETHYLENE OXIDE. Sterile disposable hypodermic needles conforming to ISO 7864: 1993. Sterility is ensured by the individual packaging of each unit and by an indicator affixed to the outer carton.
Warnings
For single use only. Do not resterilize.
storage
Store in a dry and clean place.
Validity
5 years (from sterilization) to intact packaging and if stored correctly.
Biocompatibility
All materials are biocompatible in accordance with ISO / ANSI / AAMI 10993.
Product certification
Compliant with Directive 93 / 42CEE (Annex II) (implemented by legislative decree February 24, 1997, n. 46) and subsequent additions.
Cod. 391810901/391811001/391811201/391811301/391811401
